The RIEGL VQ-880-G is a fully integrated airborne laser scanning system for combined hydrographic and topographic surveying. The system is offered with integrated and factory-calibrated highend GNSS/IMU system and camera. Complemented by a RIEGL data recorder, the RIEGL VQ-880-G is a complete LIDAR system to be installed on various platforms in a straightforward way.
The RIEGL VQ-880-G carries out laser range measurements for high resolution surveying of underwater topography with a narrow, visible green laser beam, emitted from a powerful pulsed laser source. Subject to clarity, at this particular wavelength the laser beam penetrates water enabling measurement of submerged targets.
The RIEGL VQ-880-G comprises a high precision inertial measurement sensor for subsequent precise estimation of the instrument's exact location and orientation. A high-resolution digital camera and optionally a NEW additional infrared laser scanner are integrated to supplement the data gained by the green laser scanner. The rugged internal mechanical structure together with the dust- and splash water proof housing enables long-term operation on airborne platforms.
Main features:
·
Designed for combined
topographic and hydrographic airborne survey
·
High accuracy ranging based on
echo digitization and online waveform processing with multiple-target
capability
·
Multiple-time-around processing
for straightforward mission planning and operation
·
Concurrent full waveform output
for all measurements for subsequent full waveform analysis
·
High spatial resolution due to
measurement rate of up to 550 kHz and high scanning speed of up to 160
scans/sec
·
Integrated inertial navigation
system, infrared laser scanner, and digital camera(s)
·
Compact and robust housing
compliant with typical hatches in aircrafts and with stabilized platforms
Main Applications:
·
Coastline and Shallow Water
Mapping
·
Acquiring Base Data for Flood
Prevention
·
Measurement for Aggradation
Zones
·
Habitat Mapping
·
Surveying for Hydraulic
Engineering
·
Hydro-Archaeological-Surveying
